• Wide Supply Voltage Range from 2.0V to 5.5 V

• Outputs Sink or Source 8mA at V_CC = 4.5V

• CMOS Low Power Consumption

• Schmitt Trigger Action at All Inputs

• Typical hysteresis of 1V allows for

  transformation of slow

  changing input signals to sharply

  defined, fast transition output signals.

• Inputs can be driven by 3.3V or

  5.5V allowing for voltage

  translation applications.

• ESD Protection Exceeds JESD 22

  200-V Machine Model (A115-A)

  2000-V Human Body Model (A114-A)

  Exceeds 1000-V Charged Device Model (C101C)

• Latch-Up Exceeds 250mA per JESD 78, Class II

• Range of Package Options SO-14 and TSSOP-14

• Totally Lead-Free & Fully

  RoHS Compliant (Notes 1 & 2)

• Halogen and Antimony Free.

 “Green” Device (Note 3)
