74AHC244Q.pdf• AEC-Q100 Qualified for Automotive Applications
Device Temperature Grade 1TA = -40℃ to +125℃
• Wide Supply Voltage Range: 2.0V to 5.5V
• All Inputs with Schmitt-Trigger Action
• Input Level: CMOS Level
• CMOS Low Power Dissipation
• Inputs are Over-Voltage Tolerant
• -40℃ to +125℃ Operating Temperature Range
• Available in a Green TSSOP-20 Package
• Automotive product qualification
in accordance with AEC-Q100 (Grade 1)
• Specified from -40 °C to +85 °C
and from -40 °C to +125 °C
• Wide supply voltage range from 2.0 V to 5.5 V
• Balanced propagation delays
• All inputs have Schmitt-trigger action
• Overvoltage tolerant inputs to 5.5 V
• High noise immunity
• CMOS low power dissipation
• HBM JESD22-A114F exceeds 2000 V
• MM JESD22-A115-A exceeds 200 V (C = 200 pf, R = 0 Ω)
• Latch-up performance exceeds
100 mA per JESD 78 Class II Level A
• Multiple package options
• DHVQFN package with Side-Wettable Flanks
enabling Automatic Optical Inspection (AOI) of solder jointsel
