• 8-bit serial-in, parallel-out shift

• Wide operating voltage range of 2 V to 6 V

• High-current 3-state outputs can drive up to 15

  LSTTL loads

• Low power consumption: 80-μA (maximum) ICC

• tpd = 13 ns (typical)

• ±6-mA output drive at 5 V

• Low input current: 1 μA (maximum)

• Shift register has direct clear

• On products compliant to MIL-PRF-38535,

  all parameters are tested unless otherwise noted.

  On all other products, production processing does

  not necessarily include testing of all parameters.
