• Output Drive Capability: 10 LSTTL Loads

• Outputs Directly Interface to CMOS, NMOS, and TTL

• Operating Voltage Range: 2.0 to 6.0 V

• Low Input Current: 1µA

• High Noise Immunity Characteristic of CMOS Devices

• In Compliance with JEDEC Standard No. 7 A Requirements

• Chip Complexity: 56 FETs or 14 Equivalent Gates

• NLV Prefix for Automotive and Other Applications Requirin

  g Unique Site and Control Change Requirements;

  AEC−Q100 Qualified and PPAP Capable

• These Devices are Pb−Free, Halogen Free and

   are RoHS Compliant
