74ALVC164245.pdf• 5V Tolerant Inputs/Outputs for Interfacing with 5V Logic
• Wide Supply Voltage Range:
3V VCCA: 1.5V to 3.6V 5V VCCB: 1.5V to 5.5V
• CMOS Low Power Consumption
• Direct Interface with TTL Levels
• Control Inputs Voltage Range from 2.7V to 5.5V
• Inputs Accept Voltages up to 5.5V
• High-Impedance Outputs when VCCA or VCCB = 0V
• -40℃ to +125℃ Operating Temperature Range
• Available in a Green TSSOP-48 Package
• Wide supply voltage range:
• 3 V port (VCC(A)): 1.5 V to 3.6 V
• 5 V port (VCC(B)): 1.5 V to 5.5 V
• CMOS low power consumption
• Overvoltage tolerant inputs to 5.5 V
• Direct interface with TTL levels
• IOFF circuitry provides partial
Power-down mode operation
• Latch-up performance exceeds
100 mA per JESD 78 Class II Level B
• Control inputs voltage range from 2.7 V to 5.5 V
• High-impedance outputs when VCC(A) or VCC(B) = 0 V
• Complies with JEDEC standards:
• HBM JESD22-A114F exceeds 2000 V
• MM JESD22-A115-A exceeds 200 V
• Specified from -40 °C to +85 °C and -40 °C to +125 °C
