74ALVC164245.pdf• 5V Tolerant Inputs/Outputs for Interfacing with5V Logic
3V VCCA: 1.5V to 3.6V
5V VCCB: 1.5V to 5.5V
• CMOS Low Power Consumption
• Direct Interface with TTL Levels
• Control Inputs Voltage Range from 2.7V to 5.5V
• Inputs Accept Voltages up to 5.5V
• High-Impedance Outputs when VCCA or VCCB = 0V
• -40℃ to +125℃ Operating Temperature Range
• Available in a Green TSSOP-48 Package
• 5 V tolerant inputs/outputs for interfacing with 5 V logic
• Wide supply voltage range:
3 V port (VCC(A)): 1.5 V to 3.6 V
5 V port (VCC(B)): 1.5 V to 5.5 V
• CMOS low power consumption
• Direct interface with TTL levels
• Control inputs voltage range from 2.7 V to 5.5 V
• Inputs accept voltages up to 5.5 V
• High-impedance outputs when VCC(A) or VCC(B) = 0 V
• Complies with JEDEC standard JESD8-B/JESD36
• ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
• Specified from -40℃ to +85℃ and -40 ℃ to +125℃
