• Wide Operating VCC Range of 0.9 V to 3.6 V

• Balanced Propagation Delays: tPLH = tPHL

  (1.8-V to 3.3-V Translation Typical)

• Low Static-Power Consumption: Maximum of 5-µA ICC

• ±6-mA Output Drive at 3 V

• Ioff Supports Partial Power-Down-Mode Operation

• VCC Isolation Feature – If VCCA Input Is at GND,

  B Port Is in the High-Impedance state

• Input Hysteresis Allows Slow Input Transition

  and Better Switching Noise Immunity at Input

• ESD Protection Exceeds JESD 22

• 5000-V Human-Body Model (A114-A)

• Latch-Up Performance Exceeds 100 mA

  Per JESD 78, Class II
