• Control Inputs VIH/VIL Levels Are

  Referenced to V_CCA Voltage

• V_CC Isolation Feature – If Either

   V_CC Input Is at GND, Both Ports Are

   in the High-Impedance State

• Overvoltage-Tolerant Inputs and

   Outputs Allow Mixed-Voltage-Mode

   Data Communications

• Fully Configurable Dual-Rail

  Design Allows Each Port to Operate

  Over the Full 1.2 V to 3.6 V Power-Supply Range

• Ioff Supports Partial-Power-Down Mode Operation

• I/Os Are 4.6 V Tolerant

• Maximum Data Rates

  380 Mbps (1.8 V to 3.3 V Level-Shifting)

  200 Mbps (<1.8 V to 3.3 V Level-Shifting)

  200 Mbps (Level-Shifting to 2.5 V or 1.8 V)

  150 Mbps (Level-Shifting to 1.5 V)

  100 Mbps (Level-Shifting to 1.2 V)

• Latch-Up Performance Exceeds 100 mA Per JESD 78, Class

• ESD Protection Exceeds JESD 22

  8000-V Human-Body Model (A114-A)

  200-V Machine Model (A115-A)

  1000-V Charged-Device Model (C101)
