• Single supply voltage translator

  at 1.8 V, 2.5 V, 3.3 V and 5.0 V

• Up translation

• 1.2 V to 1.8 V at VCC = 1.8 V

• 1.5 V to 2.5 V at VCC = 2.5 V

• 1.8 V to 3.3 V at VCC = 3.3 V

• 3.3 V to 5.0 V at VCC = 5.0 V

• Down translation

• 3.3 V to 1.8 V at VCC = 1.8 V

• 3.3 V to 2.5 V at VCC = 2.5 V

• 5.0 V to 3.3 V at VCC = 3.3 V

• 5 V tolerant inputs

• Latch-up performance exceeds 250 mA per JESD 78 Class II

• ESD protection:

• HBM ANSI/ESDA/JEDEC JS-001 Class 2 exceeds 2000 V

• CDM JESD22-C101F exceeds 1000 V

• Specified from -40 °C to +85 °C and from -40 °C to +125 °C
