74LVC138XS16G.pdf• Wide Supply Voltage Range: 1.2V to 3.6V
• Inputs Accept Voltages up to 5V with 5V Logic
• Mutually Exclusive Outputs
• Multiple Input Enable in favor of Expansion
• Operate as a Demultiplexer
• Memory Selector
• CMOS Low Power Dissipation
• Inputs are Compatible with TTL Levels
• Output Drive Capability: 50Ω Transmission Lines at +125℃
• -40℃ to +125℃ Operating Temperature Range
• Functional Operation from -10℃ to +85℃ at VCC = 1.14V
• Available in Green TQFN-2.5×3.5-16L, SOIC-16 and TSSOP-16 Packages
• Overvoltage tolerant inputs to 5.5 V
• Wide supply voltage range from 1.2 V to 3.6 V
• CMOS low power consumption
• Direct interface with TTL levels
• Demultiplexing capability
• Multiple input enable for easy expansion
• Ideal for memory chip select decoding
• Mutually exclusive outputs
• Output drive capability 50 Ω transmission lines at 125 °C
• Complies with JEDEC standard:
• JESD8-7A (1.65 V to 1.95 V)
• JESD8-5A (2.3 V to 2.7 V)
• JESD8-C/JESD36 (2.7 V to 3.6 V)
• ESD protection:
• HBM JESD22-A114F exceeds 2000 V
• MM JESD22-A115-B exceeds 200 V
• CDM JESD22-C101E exceeds 1000 V
• Specified from -40 °C to +85 °C and from -40 °C to +125 °C
