Available in the Ultra-Small 0.64-mm2

• Package (DPW) with 0.5-mm Pitch

• Supports 5-V VCC Operation

• Inputs Accept Voltages up to 5.5 V

  Allowing Down Translation to VCC

• Max tpd of 3.3 ns at 3.3-V

  Low Power Consumption, 10-μA Max I

  ±24-mA Output Drive at 3.3-V

  Ioff Supports Live-Insertion, Partial-

  Power-Down Mode, and Back-Drive Protection

• Latch-Up Performance Exceeds

  100 mA Per JESD 78, Class II

• ESD Protection Exceeds JESD 22

  2000-V Human-Body Model (A114-A)

  200-V Machine Model (A115-A)

  1000-V Charged-Device Model (C101)
