• Available in the Ultra Small 0.64-mm2

  Package (DPW) With 0.5-mm Pitch

• Supports 5-V VCC Operation

• Input and Open-Drain Output Accept Voltages up to 5.5 V

• Can Translate Up or Down

• Max tpd of 4.2 ns at 3.3 V

• Low Power Consumption, 10-µA Max ICC

• ±24-mA Output Drive at 3.3 V

  Ioff Supports Live Insertion, Partial-Power

  Down Mode, and Back-Drive Protection

  Latch-Up Performance Exceeds 100 mA

  Per JESD 78, Class II

• ESD Protection Exceeds JESD 22

  2000-V Human-Body Model (A114-A)

  200-V Machine Model (A115-A)

  1000-V Charged-Device Model (C101)
