• ESD Protection Exceeds JESD 22

  2000-V Human-Body Model (A114-A)

  1000-V Charged-Device Model (C101)

• Qualified from –40°C to +125°C

• Supports 5-V VCC Operation

• Inputs Are Over Voltage Tolerant up to 5.5 V

• Supports Down Translation to VCC

• Maximum tpd of 4 ns at 3.3 V and 15-pF load

• Low Power Consumption, 10-µA Maximum ICC At 85°C

• ±24-mA Output Drive at 3.3 V

• Ioff Supports Partial-Power-Down

  Mode, and Back-Drive Protection

• Available in the Texas Instruments

  NanoFree™ Package

• Latch-Up Performance Exceeds 100 mA Per

  JESD 78, Class II
