• ESD Protection Exceeds JESD 22

  2000-V Human-Body Model (A114-A)

  200-V Machine Model (A115-A)

  1000-V Charged-Device Model (C101)

• Available in the Texas Instruments NanoFree™

  Package

• Fully Configurable Dual-Rail Design Allows Each

  Port to Operate Over the Full 1.65-V to 5.5-V

  Power-Supply Range

• VCC Isolation Feature – If Either VCC Input Is at

  GND, Both Ports Are in the High-Impedance State

• DIR Input Circuit Referenced to VCCA

• Low Power Consumption, 4-μA Max ICC

• ±24-mA Output Drive at 3.3 V

• Ioff Supports Partial-Power-Down Mode Operation

• Max Data Rates

  420 Mbps (3.3-V to 5-V Translation)

  210 Mbps (Translate to 3.3 V)

  140 Mbps (Translate to 2.5 V)

  75 Mbps (Translate to 1.8 V)

• Latch-Up Performance Exceeds 100 mA Per

  JESD 78, Class II
