• 5 V tolerant inputs/outputs for interfacing with 5 V logic

• Wide supply voltage range from 1.2 V to 3.6 V

• CMOS low-power consumption

• Direct interface with TTL levels

• Inputs accept voltages up to 5.5 V

• High-impedance when VCC = 0 V

• Bus hold on all data inputs (74LVCH244A only)

• Complies with JEDEC standard:

• JESD8-7A (1.65 V to 1.95 V)

• JESD8-5A (2.3 V to 2.7 V)

• JESD8-C/JESD36 (2.7 V to 3.6 V)

• ESD protection:

• HBM JESD22-A114F exceeds 2000 V

• MM JESD22-A115B exceeds 200 V

• CDM JESD22-C101E exceeds 1000 V

• Specified from 40 C to +85 C and 40 C to +125 C
