• Floating channel designed for bootstrap operation

• Fully operational to +600 V

• Tolerant to negative transient voltage, dV/dt immune

• Gate drive supply range from 10 V to 20 V

   (IR2136/
IR21368), 11.5 V to 20 V (IR21362D), or

   12 V to 20 V
(IR21363/IR21365/IR21366/IR21367)

• Undervoltage lockout for all channels

• Over-current shutdown turns off all six drivers

• Independent 3 half-bridge drivers

• Matched propagation delay for all channels

• Cross-conduction prevention logic

• Low side output out of phase with inputs.

   High side outputs
out of phase (IR213(6,63, 65, 66, 67, 68)),

   or in phase
(IR21362) with inputs

• 3.3 V logic compatible

• Lower di/dt gate drive for better noise immunity

• Externally programmable delay for automatic fault clear

• All parts are LEAD-FREE
