• Qualified for automotive applications

• Low power operation

• 5 V operation

• 1.0 mA per channel maximum at 0 Mbps to 2 Mbps

• 3.5 mA per channel maximum at 10 Mbps

• 31 mA per channel maximum at 90 Mbps

• 3 V operation

• 0.7 mA per channel maximum at 0 Mbps to 2 Mbps

• 2.1 mA per channel maximum at 10 Mbps

• 20 mA per channel maximum at 90 Mbps

• Bidirectional communication

• 3 V/5 V level translation

• High temperature operation: 125°C

• High data rate: dc to 90 Mbps (NRZ)

• Precise timing characteristics

• 2 ns maximum pulse width distortion

• 2 ns maximum channel-to-channel matching

• High common-mode transient immunity: >25 kV/μs

• Output enable function

• 16-lead SOIC wide body package

• RoHS-compliant models available

• Safety and regulatory approvals

• UL recognition: 2500 V rms for 1 minute per UL 1577

• CSA Component Acceptance Notice 5A

• VDE Certificate of Conformity

• DIN V VDE V 0884-10 (VDE V 0884-10):2006-12

• VIORM = 560 V peak

• TÜV approval: IEC/EN/UL/CSA 61010-1
