• Designed for Wireless or Cellular Handsets and PDAs

• 1.7 W Into 8 Ω From a 5-V Supply at THD = 10%(Typical)

• Low Supply Current: 4 mA Typical at 5V

• Shutdown Current: 0.01 µA Typical

• Fast Start-Up With Minimal Pop

• Only Three External Components

 – Improved PSRR (−80 dB) and Wide Supply Voltage

  (2.5 V to 5.5 V) for Direct Battery Operation

 – Fully Differential Design Reduces RF

  Rectification

 – −63-dB CMRR Eliminates Two Input Coupling

  Capacitors

• Pin-to-Pin Compatible With TPA2005D1 and

  TPA6211A1 in SON Package

• Available in 3 mm × 3 mm SON Package (DRB)
