SCT2220.pdf• Wide Input Voltage: 4.2-17V
• 2A Continuous Output Current with
Integrated 90mΩ/65mΩFETs
• Wide Output Voltage Range:0.8V-7V
• Quiescent Current 135µA
• Cycle-by-Cycle Current Limiting
• Internal 2.5ms Soft-Start
Limits the inrush current
• Fixed 750kHz Switching Frequency
• Input Under-Voltage Lockout
• Power save mode at light load
• Over-Temperature Protection
• Available in a SOT563 and TSOT23 Package
• Wide 4.7V-to-16V Operating Input Range
• 163mΩ/86mΩ Low-RDS(ON) Internal Power
MOSFETs
• Proprietary Switching-Loss–Reduction
Technique
• High-Efficiency Synchronous-Mode
Operation
• Fixed 500kHz Switching Frequency
• AAM Power-Save Mode for High Efficiency
at Light Load
• Internal Soft-Start
• Over-Current Protection and Hiccup
• Thermal Shutdown
• Output Adjustable from 0.8V
• Available in a 6-pin TSOT-23 package
• GameStations
• Digital Set-Top Boxes
• Flat-Panel Television and Monitors
• General Purposes
