• Wide Input Voltage Range

• 4.5V to 60V

• 4V to 60V (Soft-start is finished)

• Wide Output Voltage Range : 0.8V to VIN

• 0.8V ±1% Reference Accuracy

• Peak Current Mode Control

• Integrated 80mΩ High-Side MOSFET

• Low Quiescent Current : 100μA

• Low Shutdown Current : 2.25μA

• Adjustable Switching : 100kHz to 2.5MHz

• Synchronizable Switching : 300kHz to 2.2MHz

• Power Saving Mode (PSM) at Light Load

• Low Dropout at Light Loads with Integrated Boot

  Recharge FET

• Externally Adjustable Soft-Start by Part Number

  Option

• Power Good Indication by Part Number Option

• Enable Control

• Adjustable UVLO Voltage and Hysteresis

• Built-In UVLO, UVP, OVP, OCP, OTP
