• Qualified for Automotive Applications

• AEC-Q100 Qualified With the Following Results:

  Device Temperature Grade 1: –40°C to 125°C

  Ambient Operating Temperature Range

  Device HBM ESD Classification Level H2

  Device CDM ESD Classification Level C4B

• Quad-Channel 1000-mΩ Smart High-Side Switch

  With Full Diagnostics

  Version A: Open-Drain Status Output

  Version B: Current-Sense Analog Output

• Wide Operating Voltage 3.4 to 40 V

• Ultralow Standby Current, <500 nA

• High-Accuracy Current Sense:

  ±15% Under >5-mA Load

• Adjustable Current Limit With External Resistor

  ±20% Under >100-mA Load

• Protection:

  Short-to-GND Protection by Current Limit

  (Internal or External)

  Thermal Shutdown With Latch-Off Option and

  Thermal Swing

  Inductive Load Negative Voltage Clamp With

  Optimized Slew Rate

  Loss of GND and Loss of Battery Protection

• Diagnostic:

  Overcurrent and Short to Ground Detection

  Open-Load and Short-to-Battery Detection

  Global Fault for Fast Interrupt

• 20-Pin Thermally-Enhanced PWP Package
