• Optimized performance at a low supply current of 1.2 mA

• Covers full GNSS L1 band, from 1559 MHz to 1610 MHz

• Noise figure = 0.80 dB

• Gain 17.5 dB

• Input 1 dB compression point of -16 dBm

• Out of band IP3_i of -8 dBm

• Supply voltage 1.5 V to 3.1 V

• Self-shielding package concept

• Integrated supply decoupling capacitor

• Power-down mode current consumption < 1 mA

• Integrated temperature stabilized bias for easy design

• Requires only one input matching inductor

• Integrated DC blocking at both RF input and output

• ESD protection on all pins (HBM > 2 kV)

• Integrated matching for the output

• Available in a 6-pin leadless package 1.1 mmx0.7 mm

  x0.37 mm; 0.4 mm pitch: SOT1232

• 180 GHz transit frequency - SiGe:C technology

• Moisture sensitivity level 1
