• Frequency range from 1.8GHz to 2.7GHz

• Two operation modes

  Low noise mode:

    14dB gain, 0.8dB noise figure at 1800MHz

    to 2200MHz;

    13dB gain, 0.9dB noise figure at 2300MHz

    to 2700MHz

    Bypass mode: 2 dB insertion loss, 15dBm

    input P1dB

• Low noise mode current 7 mA & bypass

  mode current less than 1uA

• Single supply voltage range 1.6V to 3.0V

• Small package 1.1mmx0.7mmx0.45mm

• Low cost BOM

• Lead-Free and RoHS-Compliant
