_{• Input Voltage Range: 2.7V to 20V}

_{• Low Noise:}

  _{9.3μVRMS at VOUT = 1.2V}

  _{11μVRMS at VOUT = 2.8V}

  _{14μVRMS at VOUT = 5.0V}

_{• PSRR (VIN = VOUT(NOM) + 1V):}

  _{100dB at 1kHz}

  _{83dB at 10kHz}

  _{52dB at 100kHz}

  _{55dB at 1MHz}

_{• Maximum Output Current: 500mA}

_{• Output Voltage Accuracy: ±1% at +25℃}

_{• Low Dropout Voltage:}

  _{360mV (TYP) at 500mA Load when VOUT = 5.0V}

_{• User Programmable Soft-Start (TDFN Package Only)}

_{• Low Quiescent Current: 39μA (TYP)}

_{• Shutdown Current: 1.2μA (TYP)}

_{• Stable with a 2.2μF Ceramic Output Capacitor}

_{• Adjustable Output from 1.2V to (VIN - VDROP),}

  _{Output can be Adjusted above Initial Set Point}

_{• Reverse Current Protection when VOUT > VIN}

_{• Foldback Current-Limit Protection when}

  _{VOUT isShorted to GND}

_{• Automatic VOUT Discharge when Disabled}

_{• Precision Enable}

_{• -40℃ to +125℃ Operating Temperature Range}

_{• Available in Green TDFN-2×2-6AL}

  _{and SOT-23-5Packages}
