SGM2537.pdf• Input Voltage: 2.7V to 18V, Surge up to 20V
• Low On-Resistance: 35mΩ (TYP)
• Output Clamp Response Time: 5μs (TYP)
• Programmable Current Limit: 0.5A to 4A
• ±7.5% Current Limit Accuracy
• Load Current Monitor Output
• Programmable Soft-Start Time (SS)
• Over-Temperature Protection (OTP)
• Fault Flag (nFAULT Pin)
• Available in a Green TDFN-2×2-8AL Package
• Wide Input Voltage Range: 2.7 V to 18 V
– 20-V Absolute Maximum
– 3 V to 18 V for TPS2595x5 version
• Low On-Resistance: RON = 34 mΩ (typical)
• Overvoltage Protection Clamp (3.8-, 5.7-, and
13.7-V options)
• Adjustable Undervoltage Lockout (UVLO)
• Adjustable Current Limit with Monitor Output (ILM)
– Current Range: 0.5 A to 4 A
– Current Accuracy: ±10% (≥2 A)
• Fast Short Circuit Protection
• Adjustable Output Slew Rate Control (dVdt)
• Over Temperature Protection (OTP)
• Fault Indication Pin (FLT)
• UL 2367 Recognition (Pending)
• Safe During Single Point Failure Test (UL60950)
