SGM2560AYS8G.pdf• 90mΩ (TYP) High-side MOSFET per Channel
• 1.1A Current Limit
• Input Voltage Range: 2.7V to 5.5V
• Low Quiescent Current: 28μA (Dual-Channel)
• Soft-Start Function
• Short-Circuit Protection with Thermal Shutdown
• Thermally Isolated Channels
• Fault Status Flag with 4ms Filter Eliminates False
Assertions
• Under-Voltage Lockout Protection for VIN
• No Reversed Leakage Current
• 1.8V Logic-Compatible Inputs
• Available in the Green SOIC-8 and TDFN-3×3-8L
Packages
• 80-mW High-Side MOSFET Switch
• 500 mA Continuous Current Per Channel
• Independent Thermal and Short-Circuit
Protection With Overcurrent Logic Output
• Operating Range . . . 2.7 V to 5.5 V
• CMOS- and TTL-Compatible Enable Inputs
• 2.5-ms Typical Rise Time
• Undervoltage Lockout
• 10 mA Maximum Standby Supply Current
for Single and Dual (20 mA for Triple and
Quad)
• Bidirectional Switch
• Ambient Temperature Range, 0°C to 85°C
• ESD Protection
• UL Listed – File No. E169910
