• Low Differential Gain and Phase

  (D_G = 0.64%, D_P = 0.1 Degrees Typ)

• Wide Bandwidth (BW = 300 MHz Min)

• Low Crosstalk (X_TALK = –63 dB Typ)

•  Low Power Consumption

  (I_CC = 3 mA Max)

• Bidirectional Data Flow With Near-Zero

  Propagation Delay

• Low ON-State Resistance (ron = 3 Ω Typ)

• V_CC Operating Range From 4.5 V to 5.5 V

• I_off Supports Partial-Power-Down Mode

  Operation

• Data and Control Inputs Provide Undershoot

  Clamp Diode

• Control Inputs Can Be Driven by TTL or

  5-V/3.3-V CMOS Outputs

• Latch-Up Performance Exceeds 100 mA Per

  JESD 78, Class II

• ESD Performance Tested Per JESD 22

  1000-V Charged-Device Model (C101)

• Suitable for Both RGB and Composite-Video

  Switching
