• Efficiency Optimized Switched-

  Capacitor Architecture

  Up to 6A Output Current

  3.3V to 11.5V Input Voltage Range

  200kHz to 1.5MHz Switching Frequency Setting

  Up to 97% Voltage Divider Mode Efficiency

  (when VBAT = 4V, IBAT = 3A)

• Comprehensive Integrated Protection Features

  External OVP Control and Regulation

  Input Over-Voltage Protection (BUS_OVP)

  Input Short-Circuit Protection (BUS_SC)

  Input Over-Current Protection (IBUS_OCP)

  Input Under-Current Protection (IBUS_UCP)

  Battery Over-Voltage Protection (BAT_OVP)

  Output Short-Circuit Protection (VOUT_SC)

  Battery Over-Current Protection (IBAT_OCP)

  CFLY Short-Circuit Protection (CFLY_SC)

  Converter Over-Current Protection (CONV_OCP)

  Die Over-Temperature Protection (TDIE_OTP)

• 5-Channel 12-Bit (Effective) ADC Converter

  VBUS, IBUS, VBAT, IBAT, TDIE Monitoring
