• Single H-Bridge Current-Control Motor Driver

• 8.2-V to 45-V Operating Supply Voltage Range

• Five-Bit Winding Current Control Allows Up to

  32 Current Levels

• Low MOSFET RDS(on) Typical 0.2 Ω (HS + LS)

• 5-A Maximum Drive Current at 24 V, 25°C

• Built-In 3.3-V Reference Output

• Industry-Standard PWM Control Interface

• Thermally Enhanced Surface Mount Package

• Protection Features:

  Overcurrent Protection (OCP)

  Thermal Shutdown (TSD)

  VM Undervoltage Lockout (UVLO)

  Fault Condition Indication Pin (nFAULT)
