• On-Resistance:
22Ω (TYP) with Single 36V Supply

• Low Off Leakage Current: 0.01μA (TYP)

• Low On Leakage Current: 0.01μA (TYP)

• ±3.2V to ±18V Dual-Supply Operation   or

+3.2V to +36V Single-Supply Operation

• TTL/CMOS-Logic Compatible

• Low Distortion: 0.001% (TYP)

  (RL = 600Ω, f = 1kHz)

• High Off-Isolation: -88dB

  (TYP) (RL = 50Ω, f = 1MHz)

• Low Crosstalk: -97dB (TYP)

  (RL = 50Ω, f = 1MHz)

• -40℃ to +125℃ Operating Temperature Range

• Available in Green SOIC-16, SSOP-16,

  TSSOP-16and TQFN-3×3-16L Packages
