• No External Components Required

• Shutdown Mode to Minimize Power Consumption

• Up to Eight SGM452 Devices can

  be Connected to a Single Bus

• Power-Up Defaults Permit Stand-Alone

  Operation as Thermostat

• Power Supply Voltage Range: 2.7V to 5.5V

• Support 1.8V I2C Bus Voltage at 3.3V Power Supply

• Low Quiescent Current: 49μA (TYP)

• Shutdown Mode Current: 0.4μA (TYP)

• Temperature Accuracy:

  -55℃ to +125℃: ±1.2℃ (MAX)

• Operating Temperature Range: -55℃ to +125℃

• Available in Green SOIC-8 and MSOP-8 Packages
