• Low Cost Gate Driver (offering optimal solution for driving

  FET and IGBTs)

• Superior Replacement to Discrete Transistor Pair Drive

  (providing easy interface with controller)

• TTL and CMOS Compatible Input Logic Threshold,

  (independent of supply voltage)

• Split Output Options Allow for Tuning of Turn- On and

  Turn-Off Currents

• Inverting and Non-Inverting Input Configurations

• Enable with Fixed TTL Compatible Threshold

• High 2.5-A Source and 2.5-A or 5-A Sink Peak Drive

  Currents at 18-V VDD

• Wide VDD Range From 10 V up to 35 V

• Input and Enable Pins Capable of Withstanding up to

  -5-V DC Below Ground

• Output Held Low When Inputs are Floating or During

  VDD UVLO

• Fast Propagation Delays (17-ns typical)

• Fast Rise and Fall Times
