SGM48760XN5G.pdf• Supply Voltage Range: 1.65V to 5.5V
• Low On-Resistance: 4.5Ω (TYP) at VCC = 4.5V
• With No VCC Connected in the System, the
Control Pin can Accept Voltages up to 5.5V
• Propagation Delay Time, tPD:
0.65ns (TYP) at VCC = 3.3V
• Rail-to-Rail Input and Output Operation
• -40℃ to +125℃ Operating Temperature Range
• Available in Green SC70-5 and SOT-23-5 Packages
• Available in the Texas
Instruments NanoFree™Package
• 1.65-V to 5.5-V VCC Operation
• Inputs Accept Voltages to 5.5 V
• Max tpd of 0.8 ns at 3.3 V
• High On-Off Output Voltage Ratio
• High Degree of Linearity
• High Speed, Typically 0.5 ns (VCC = 3 V,
CL = 50 pF)
• Low ON-State Resistance, Typically ≉5.5 Ω (VCC= 4.5 V)
Latch-Up Performance Exceeds 100 mA Per
JESD 78, Class II
• ESD Protection Exceeds JESD 22
2000-V Human-Body Model (A114-A)
200-V Machine Model (A115-A)
1000-V Charged-Device Model (C101)
