SGM61020XN5G.pdf• 2.5V to 5.5V Input Voltage Range
• Adjustable Output Voltage from 0.6V to VIN
• Up to 95% Efficiency
• Low RDSON Switches (102mΩ/57mΩ)
• Power-Save Mode for Light Load Efficiency
• 42μA (TYP) Operating Quiescent Current
• 100% Duty Cycle for Low Dropout Operation
• 1.5MHz PWM Switching Frequency
• Power Good Output (SGM61020P Only)
• Over-Current Protection
• Thermal Shutdown Protection
• Input Under-Voltage Lockout (UVLO) Protection
• -40℃ to +125℃ Operating Temperature Range
VSmall Packaging:
SGM61020: Available in Green
SOT-23-5 andSOT-563-6 Packages
SGM61020P: Available in a Green
SOT-563-6Package
• 2.5V to 5.5V Input Range
• Adjustable Output From 0.6V to VIN
• 1.0V, 1.2V, 1.5V, 1.8V, 2.5V and 3.3V Fixed/
Adjustable Output Voltage
• 400mA Output Current, 1A Peak Current
• 95% Efficiency
• No Schottky Diode Required
• 1.5MHz Fixed Frequency PWM Operation
• Small SOT-23-5 and TSOT-23-5 Package
• RoHS Compliant and Halogen Free
