• 2.5V to 5.5V Input Voltage Range

• Adjustable Output Voltage from 0.6V to VIN

• Up to 95% Efficiency

• Low RDSON MOSFET Switches (100mΩ/55mΩ)

• Power-Save Mode for Light Load Efficiency

• 42μA (TYP) Operating Quiescent Current

• 100% Duty Cycle Capability for Low Dropout

• 1.5MHz PWM Switching Frequency

• Power Good Output (SGM61020P Only)

• Over-Current Protection

• Thermal Shutdown Protection

• Input Under-Voltage Lockout (UVLO) Protection

• Small Packaging:

  SGM61020: Available in Green SOT-23-5 and

  SOT-563-6 Packages

  SGM61020P: Available in a Green SOT-563-6

  Package
