• 2.5V to 5.5V Input Voltage Range

• 0.6V to VIN Adjustable Output Voltage Range

• Up to 3A Output Current

• 95% Peak Efficiency

• 1.5MHz (TYP) Switching Frequency

• Low RDSON Internal Switches: 58.5mΩ/26.5mΩ

• Improved Light Load Efficiency with PSM

• Low Dropout with 100% Duty Cycle

• Reduce the IQ to 32μA (TYP) when Low Dropout

• 42μA Operating Quiescent Current

• 0.1μA (TYP) Shutdown Quiescent Current

• PG Output (Except for the SGM61032A)

• Internal Soft-Start with Pre-biased Startup

• Output Discharge at Shutdown

• Hiccup Mode OCP/Short-Circuit Protection

• Thermal Shutdown Protection

• Available in a Green SOT-563-6 Package
