SGM61720.pdf• Integrated 100mΩ/75mΩ Power MOSFETs
• Wide 6V to 60V Input Voltage Range
• 2.5A/5V Output Current Capability
• Constant On-Time (COT) Control
• Power-Save Mode and PWM Mode
• 1ms Internal Soft-Start for Inrush Current Limit
• Up to 24V Adjustable Output Voltage
• Pre-biased Startup
• -40℃ to +125℃ Operating JunctionTemperature Range
• Available in a Green SOIC-8 (Exposed Pad)Package
• Low RDS(ON) for Internal Switches
(Top/Bottom):500mΩ/240mΩ
• 7-85V Input Voltage Range
• 1.2A Continuous, 1.8A Peak
Output CurrentCapability
• Adjustable Switching Frequency
• Instant PWM Architecture to
Achieve FastTransient Responses
• Programmable Switching
Frequency Range:200~500 kHz
• 2ms Internal Soft-start Limits
the Inrush Current
• Precise ±2% 1.2V Reference
• RoHS Compliant and Halogen Free
• Compact Package: SO8E
