• Ultra-Low Supply Current: < 1μA (TYP)

• Precision Supply-Voltage Monitor

  4.63V for SGM706B-L

  4.38V for SGM706B-M

  4.0V for SGM706B-J

  3.08V for SGM706B-T

  2.93V for SGM706B-S

  2.63V for SGM706B-R

• Guaranteed nRESET Valid at V_CC = 1V

• 200ms Reset Pulse Width

• Debounced TTL/CMOS-Compatible

• Manual Reset Input

• Independent Watchdog Timer (1.6s) Timeout

• Voltage Monitor for Power-Fail

  or Low-BatteryWarning

• -40℃ to +125℃ Operating Temperature Range

• Available in Green SOIC-8 and MSOP-8 Packages
