• Supply Voltage Range: 2.7V to 5V

• Supports USB Type-C Specification 1.1

• Enable Control: Active Low (EN Pin)

• Backward Compatible with USB Type-C

  Specification 1.0

• Supports up to 3A of Current Advertisement and

  Detection

• Mode Configuration

  Host Only - DFP (Source)

  Device Only - UFP (Sink)

  Dual Role Port - DRP

  Try.SNK

• Channel Configuration (CC)

  Attachment of USB Port Detection

  Cable Orientation Detection

  Role Detection

  Type-C Current Mode (Default, Medium or High)

• VBUS Detection

• I2C or GPIO Control

• Role Configuration Control through I2C

• Low Current Consumption

• -40℃ to +125℃ Operating Temperature Range

• Available in Green UTQFN-1.6×1.6-12L Package
