SGM7SZ125.pdf• Ultra-High Speed: tPD = 3.5ns (TYP)
into 50pFat VCC = 3.3V
• High Output Drive:
±24mA at VCC = 3V
• Broad VCC Operating
Range: 1.65V to 5.5V
• Matches Performance of LCX
Operated atVCC = 3.3V
• Power Down High-Impedance
Inputs/Output
• Over-Voltage Tolerant Inputs
Facilitate 5V to 3VTranslation
• Available in Green SOT-23-5
and SC70-5 Packages
• Ultra−High Speed: tPD = 2.6
ns (Typical) into 50 pF at 5 V VCC
• High Output Drive: ±24 mA at 3 V VCC
• Broad VCC Operating Range: 1.65 V to 5.5 V
• Matches Performance of LCX
when Operated at 3.3 V VCC
• Power Down High−Impedance
Inputs / Outputs
• Over−Voltage Tolerance Inputs
Facilitate 5 V to 3 V Translation
• Proprietary Noise / EMI
Reduction Circuitry
• Ultra−Small MicroPak™ Packages
• Space−Saving SC−74A and
SC−88A Packages
• These Devices are Pb−Free, Halogen
Free/BFR Free and are RoHSCompliant
