SGM7SZ244.pdf• Wide Operating Voltage Range: 1.8V to 5.0V
• High-Current Outputs Drive Up to 15 LSTTL
Loads
• 3-State Outputs Drive Bus Lines or Buffer
Memory Address Registers
• Low Power Consumption, ICC: 25μA (MAX)
• Typical tPD = 8.9ns at 5.0V
• ±20mA Output Drive at 5.0V
• Low Input Current: ±8μA (MAX)
• -40℃ to +125℃ Operating Temperature Range
• Available in a Green TSSOP-20 Package
• AEC-Q100 (Rev. H) (Note 1)
• Wide operating temperature range: Topr = -40 to 125℃
• High speed: tpd = 3.9 ns (typ.) at VCC = 5 V
• Low power dissipation: ICC = 4.0
µA (max) at Ta = 25℃
• High noise immunity: VNIH = VNIL = 28 % VCC (min)
• Power down protection is provided on all inputs.
• Balanced propagation delays: tPLH≈ tPHL
• Wide operating voltage range: VCC(opr) = 2.0 V to 5.5 V
• Low noise: VOLP = 0.8 V (max)
• Pin and function compatible with the 74 series
(AC/HC/AHC/LV etc.) 240 or 244 type.
