7SZ245XTS20G/TR.pdf• Wide Operating Voltage Range: 1.8V to 5.0V
• High-Current 3-State Outputs Drive Bus Lines
Directly or Up to 15 LSTTL Loads
• Low Power Consumption, ICC: 0.1μA (TYP)
• Typical tPD = 12ns
• ±20mA Output Drive at 5V
• Low Input Current: ±0.1nA (TYP)
• Available in Green TSSOP-20, TQFN-5.5×3.5-24L
and TQFN-3×3-20L Packages
• 5V TOLERANT INPUTS AND OUTPUTS
• HIGH SPEED :
tPD = 7.0 ns (MAX.) at VCC = 3V
• POWER DOWN PROTECTION ON INPUTS
AND OUTPUTS
• SYMMETRICAL OUTPUT IMPEDANCE:
|IOH|=IOL = 24mA (MIN) at VCC = 3V
• PCI BUS LEVELS GUARANTEED AT 24 mA
• BALANCED PROPAGATION DELAYS:
tPLH ≅ tPHL
• OPERATING VOLTAGE RANGE:
VCC(OPR) = 2.0V to 3.6V (1.5V Data Retention)
• PIN AND FUNCTION COMPATIBLE WITH 74 SERIES 245
• LATCH-UP PERFORMANCE EXCEEDS
500mA (JESD 17)
• ESD PERFORMANCE:
HBM > 2000V (MIL STD 883 method 3015); MM > 200V
