• Low Cost

• Rail-to-Rail Output

• 2mV Typical VOS

• High Speed

   250MHz, -3dB Bandwidth (G = +1)

   130V/μs, Slew Rate

   58ns Settling Time to 0.1% with 2V Step

• Supply Voltage Range: 2.5V to 5.5V

• Input Voltage Range: -0.2V to +3.8V with VS = 5V

• Excellent Video Specs (RL = 150Ω, G = +2)

   Gain Flatness 0.1dB to 37MHz

   Diff Gain: 0.03%, Diff Phase: 0.08 Degree

• Low Supply Current 2.3mA/Amplifier (TYP)

• Small Packaging Available in SOT-23-5 and SOIC-8
