• Dual Operational Amplifiers

• Voltage Feedback

• High Open-Loop Gain: 110dB

• Unity-Gain Stable

• Support Single or Dual Power Supplies:

  4.5V to 36V or ±2.25V to ±18V

• Rail-to-Rail Output

  High Linear Output Current:

  310mA Peak Current into 32Ω

  on ±12V SuppliesWhile Maintaining -55dBc SFDR

• Ultra-Low Noise:3.5nV/ Hz Voltage

  Noise Density at 100kHz4pA/ Hz Current

  Noise Density at 100kHz

• High Speed:22MHz Bandwidth (G = +1, -3dB)

  33V/μs Slew Rate (RLOAD = 32Ω)

• -40℃ to +85℃ Operating Temperature Range

• Available in Green SOIC-8 and TDFN-3×3-8BLPackages
