SGM8270-2.pdf• Wide Input Common Mode and
DifferentialVoltage Ranges
• Low Input Bias and Offset Current
• Output Short-Circuit Protection
• Rail-to-Rail Input and Output
• High Input Impedance
• Low Offset Voltage: 2.8mV (MAX)
• Low Noise: 15nV/ Hz at 1kHz
• Gain-Bandwidth Product: 2.5MHz
• High Slew Rate: 8V/µs
• -40℃ to +125℃ Operating Temperature Range
• Available in Green SOIC-8 and MSOP-8 Packages
• Wide Bandwidth: 4.5 MHz
• High Slew Rate: 13 V/µs
• Fast Settling Time: 1.1 µs to 0.1%
• Wide Single Supply Operation: 3.0 V to 44 V
• Wide Input Common Mode
Voltage Range: Includes Ground (VEE)
• Low Input Offset Voltage: 3.0 mV Maximum (A Suffix)
• Large Output Voltage Swing:
14.7 V to +14 V (with ±15 VSupplies)
• Large Capacitance Drive Capability: 0 pF to 10,000 pF
• Low Total Harmonic Distortion: 0.02%
• Excellent Phase Margin: 60°
• Excellent Gain Margin: 12 dB
• Output Short Circuit Protection
• ESD Diodes/Clamps Provide Input
Protection for Dual and Quad
• NCV Prefix for Automotive and Other
Applications RequiringUnique Site and
Control Change Requirements;
AEC−Q100Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen
Free/BFR Free and are RoHSCompliant
