SGM8276-2.pdf• Wide Input Common Mode and Differential VoltageRanges
• Low Input Bias and Offset Current
• Output Short-Circuit Protection
• Rail-to-Rail Input and Output
• High Input Impedance
• Low Offset Voltage: 0.3mV (TYP), 1.5mV (MAX)
• Low Noise: 10nV/Hz at 1kHz
• Gain-Bandwidth Product: 10MHz
• High Slew Rate: 8V/μs
• -40℃ to +125℃ Operating Temperature Range
• Small Packaging:
SGM8276-1 Available in a Green SOT-23-5 Package
SGM8276-2 Available in a Green SOIC-8 Package
SGM8276-4 Available in a Green SOIC-14 Package
• Supply Range: +2.7V to +36V, ±1.35V to ±18V
• Low Noise: 19nV/√Hz
CRFI Filtered Inputs
• Input Range Includes the Negative Supply
• Input Range Operates to Positive Supply
• Rail-to-Rail Output
• Gain Bandwidth: 1.2MHz
• Low Quiescent Current: 110μA per Amplifier
• High Common-Mode Rejection: 120dB
• Low Bias Current: 15pA (max)
