Low Quiescent Current, Programmable Delay Supervisory Circuit，Replace TPS3806
SGM836
SGM836.pdf
SGM836.pdfFEATURES
• Adjustable Reset Timeout Period: 1.25ms to 10s
• Low Quiescent Current: 0.6μA (TYP)
• High Threshold Accuracy: 1% (TYP)
• Factory-Set Detection Voltages from 0.9V
to 5V and Adjustable Detection Voltage Down to 0.4V
• Manual Reset (nMR) Input
• Open-Drain nRESET Output
• -40℃ to +125℃ Operating Temperature Range
• Available in Green SOT-23-6 and TDFN-2×2-6AL Packages
PIN CONFIGUTION
优势替代
FEATURES
• Dual Voltage Detector With Adjustable
Hysteresis 3.3-V/Adjustable and
• 2-V/AdjustableAssured Reset at V.8 V
• Supply Current: 3 µA Typical at VDD = 3.3 V
• Independent Open-Drain Reset Outputs
• Temperature Range: -40°C to +85°C
• 6-Pin SOT-23 Package
PIN CONFIGUTION
