SGM8770.pdf• Single Supply or Dual Supplies
• Wide Supply Voltage Range: 2.8V to 36V
• Open-Drain Output
• Low Supply Current Independent
of Supply Voltage:310μA (TYP)
• Low Input Offset Voltage: 2.4mV (MAX)
• Low Input Bias Current: ±20pA (TYP)
• Input Common Mode Voltage Range IncludesGround
• Differential Input Voltage Range Equal
toMaximum-Rated Supply Voltage: ±36V
• Low Output Saturation Voltage
• Output Compatible with TTL and CMOS
• -40℃ to +125℃ Operating Temperature Range
• Available in Green SOIC-8 and TDFN-3×3-8LPackages
• Wide Power Supply Range:
Single Supply: 2V to 36V
Dual Supplies: ±1.0V to ±18V
• Very Low Supply Current Drain
Independent of Supply Voltage
LM2903: 0.6mA LM2901: 0.9mA
• Low Input Bias Current: 25nA
• Low Input Offset Current: ±5nA
• Typical Offset Voltage:
Non-A Device: 2mV
A Device: 1mV
• Common-Mode Input Voltage
Range Includes Ground
• Differential Input Voltage Range Equal
to the Power SupplyVoltage
• Low Output Saturation Voltage:
LM2903: 200mV at 4mA
LM2901: 100mV at 4mA
• Output Voltage Compatible
with TTL, MOS and CMOS
• Totally Lead-Free & Fully
RoHS Compliant (Notes 1 & 2)
• Halogen and Antimony Free.
“Green” Device (Note 3)
