• Rail-to-Rail Output

• Low Noise: 30nV/ Hz

• Low Distortion

• Supply Voltage Range: 1.8V to 5.5V

• Low Input Offset Voltage: 0.9mV (MAX)

• Gain-Bandwidth Product: 1.5MHz

• Slew Rate: 0.8V/μs

• Low Supply Current:80μA/Amplifier (TYP)

  0.1μA Shutdown Current for SGM8933

• -40℃ to +85℃ Operating Temperature Range

• Small Packaging:

  SGM8931 Available in SOT-23-5, SC70-5, SOIC-8
  and MSOP-8 Packages

  SGM8932 Available in SOIC-8 and MSOP-8 Packages

  SGM8933 Available in SOT-23-6, SOIC-8 and
  MSOP-8 Packages

  SGM8934 Available in SOIC-14 and TSSOP-14
  Packages
