● High Efficiency 2A, 1.5MHz Switch-Mode Boost Charger

● USB On-The-Go (OTG) Support (Buck Mode) with Adjustable

   Output from 4.5V to 5.5V

● Single Input for USB Input Adapters

● Input Current Optimizer (ICO) to Maximize Input Power

   without Overloading Adapters

● High Battery Discharge Efficiency with 13mΩ Switch

● Integrated ADC for System Monitoring (BUS Voltage and

   Current, BAT Voltage, Charge Current, SYS Voltage, and

   NTC and Die Temperature)

● Narrow Voltage DC (NVDC) Power Path Management

● Flexible Autonomous and I2C Operation Modes for Optimal

   System Performance

● Fully Integrated All MOSFETs, Current Sense and Loop

   Compensation

The SGM41528 is a battery charger and system power path management device with integrated converter and power switches for use with 2-cell Li-Ion or Li-polymer batteries. I2C programming makes it a very flexible powering and charger design solution.
